Technical Specifications
| Capacity |
User Capacity |
3.000 |
| |
Card Capacity |
3.000 |
| |
Log Capacity |
100.000 |
| Interface |
Communication |
TCP/IP, RS485, USB Host, WiFi, Optional 4G |
| |
I/O |
Relay Output, Wiegand Output, Door Sensor, Switch, Doorbell |
| Feature |
Identification |
Face, Card, ID+Password |
| |
Verify Speed |
<1s |
| |
Image Display |
Support |
| |
Self-defined Status |
10 |
| |
Record Self-check |
Support |
| |
Embedded Webserver |
Support |
| |
Doorbell |
Support |
| |
Multi-languages Support |
Support |
| |
Software |
Crosschex Standard |
| Hardware |
CPU |
Dual-core 1.0GHz |
| |
Face Detection Camera |
Dual Camera |
| |
LCD |
3.2" HD TFT Touch Screen |
| |
Sound |
Support |
| |
Angle Range |
Level: ±20°, Vertical: ±20° |
| |
Verify Distance |
0.3-0.8 m (11.8-31.5 inch) |
| |
RFID Card |
Standard EM, Optional Mifare |
| |
Tamper Alarm |
Support |
| |
Operating Temperature |
-20 °C (-4 °F)- 60 °C (140 °F) |
| |
Operating Voltage |
DC 12V |
| |
Dimensions{W x H x D) |
124*155*92 mm (4.9*6.1*3.6 inch) |
| |
Operating Voltage |
DC 12V |
